Rockwell Automation Publication 1769-UM022C-EN-P - June 2018 41
Complete the Controller Setup Chapter 3
Use the SD Card to Set the lP Address
You can use an SD card to set the IP address for a Compact GuardLogix 5370
controller.
If you use the SD card to set the IP address, then it removes the need
for software to complete this task.
These requirements apply when using the SD card to set the IP address on a
Compact GuardLogix 5370 controller:
• A project must be stored on the SD card.
• The project that is stored on the SD card is configured with the Load
Image parameter set to On Power Up.
Additional requirements apply for safety projects. See Chapter 13
and the
GuardLogix 5570 and Compact GuardLogix 5370 Controllers Safety
Reference Manual, publication 1756-RM099
.
IMPORTANT To set the IP address from an SD card, software is not required during the
power-up process. However, you must have previously saved the project to
the SD card.
The IP address of the Compact GuardLogix 5370 controller is automatically
configured at power-up as long as you have configured an IP address, stored
the program onto a controller, and set the SD card to the Load Image
parameter set to On Power Up.
The option to set the IP address of a Compact GuardLogix 5370 controller via
an SD card at power-up is only one part of the process to load an entire
project to the controller from the SD card.
Use this option carefully. For example, the SD card can contain a desirable IP
address as part of an undesirable project, for example, a project that is older
than the project currently used on the controller.
