Allen-Bradley Compact GuardLogix 5370 User Manual

72 Rockwell Automation Publication 1769-UM022C-EN-P - June 2018
Chapter 5 Communicate Over Networks
EtherNet/IP Network
Communication
The EtherNet/IP network offers a full suite of control, configuration, and data
collection services by layering the Common Industrial Protocol (CIP
™) over
the standard Internet protocols, such as TCP/IP and UDP. This combination
of well-accepted standards provides the capability that is required to support
information data exchange and control applications.
The Compact GuardLogix 5370 controllers use socket interface transactions
and conventional communication over the EtherNet/IP network to
communicate with Ethernet devices that do not support the EtherNet/IP
application protocol.
For more information on socket interface transactions, see Socket Interface
on
page 77.
Available Software
You use the software that is listed in the following table with a Compact
GuardLogix 5370 controller on an EtherNet/IP network.
EtherNet/IP Functionality
The Compact GuardLogix 5370 controllers offer this EtherNet/IP network
functionality:
• Dual built-in EtherNet/IP network ports
• Support for the following EtherNet/IP network topologies:
– Device Level Ring Network Topology
–Linear Network Topology
–Star Network Topology
• Support for CIP safety protocol
• Support for Integrated Motion over an EtherNet/IP network
• Socket interface to communicate with Ethernet devices that do not
support the EtherNet/IP application protocol
Software Required Version Functions Required
Studio 5000®
environment
28.00.00 or later • Configure the CompactLogix™ project
• Define EtherNet/IP communication
• Change IP address for devices on network,
including the Compact GuardLogix 5370 controller
Yes
RSLinx® Classic 3.80 or later • Assign or change IP addresses to devices on an
EtherNet/IP network
• Configure communication devices
• Provide diagnostics
• Establish communication between devices
BOOTP/DHCP
utility
Most current version is
installed when RSLinx
Classic software is installed
Assign IP addresses to devices on an EtherNet/IP
network.
No
