Allen-Bradley Compact GuardLogix 5370 User Manual

38 Rockwell Automation Publication 1769-UM022C-EN-P - June 2018
Chapter 3 Complete the Controller Setup
Use the Studio 5000 Environment to Set the lP Address
You can use Logix Designer application to set the IP address of a Compact
GuardLogix 5370 controller. To set the IP address via the application, you must
be connected to your controller via the USB port.
Complete these steps to set the IP address of the controller.
1. Start the Logix Designer application.
2. Click RSWho to specify the project path.
The RSWho Active dialog box appears.
3. Navigate over the USB network and select the Compact GuardLogix
controller.
4. Click Set Project Path.
IMPORTANT These steps show a 1769-L36ERMS controller. The same steps also apply to
all Compact GuardLogix 5370 controllers with slight variations in screens.
