1756-6.5.3 - December 1999
4-10 Logix5550 to Logix5550 Controller: Scheduled Communication
The Module Properties window will appear.
3. Enter the following parameters:
4. Click on Finish to accept the configuration. The remote 1756-CNB
module should appear indented under the local 1756-CNB in the I/O
Configuration folder.
Name Remote_CNB
Node 1
Chassis Size (Enter your chassis size)
Slot 1
Comm Format None
Electronic Keying Compatible Module
