1756-6.5.3 - December 1999
Logix5550 Controller to PLC-5C: Scheduled Communications 6-17
10.Double-click on Controller Properties in the Project tree.
The Controller Properties window will appear:
11.Verify/Enter the following parameters:
12.Click on the Browse button and Open the RSNetWorx for ControlNet
project file created previously (e.g., “Sched_Logix5550_toPLC5.xc”).
13.Click on Apply. Then click on OK.
In this field Enter
Processor Name CONSUMER
PLC ControlNet Node 11
To Next Page
