GS980MX Series Installation Guide for Virtual Chassis Stacking
125
Note
The GS980MX/28 or GS980MX/28PSm switch only require two
brackets to mount. The GS980MX/10HSm, GS980MX/18HSm,
GS980MX/52, and GS980MX/52PSm switches are heavier and
require four brackets to mount.
Install the GS980MX/10HSm, GS980MX/18HSm, GS980MX/52, or
GS980MX/52PSm switch on a wall with the front panel facing left or right,
as shown in Figure 69. Do not install the switch with the front panel facing
up or down.
Figure 69. Positioning the GS980MX/10HSm, GS980MX/18HSm,
GS980MX/52, or GS980MX/52PSm Switch on the Wall
35179111315171921 23 27/S1
28/S2
25 SFP+
26
AT-GS980MX/28PSm
16 18 2014
10G/1G
46810122
22 24
FDX HDX COL
1G LINK ACT 100 LINK ACT 5G/2.5G/1G LINK ACT 100 LINK ACT
PORTS 21-24
PORTS 1-20
5G/2.5G/1G/100
CLASS
1
LASER PRODUCT
CONSOLE
35179111315171921 23 27/S1
28/S2
25 SFP+
26
AT-GS980MX/28PSm
16 18 2014
10G/1G
46810122 22 24
FDX HDX COL
1G LINK ACT 100 LINK ACT 5G/2.5G/1G LINK ACT 100 LINK ACT
PORTS 21-24
PORTS 1-20
5G/2.5G/1G/100
CLASS1
LASER PRODUCT
CONSOLE
