Chapter 1: Overview
52
Switch ID LED
The switch ID LED, shown in Figure 19, displays the ID number of the
switch. A standalone switch has the ID number 0. Switches in a VCStack
have the numbers 1 to 4. Chapter 7, “Building the Trunk with the Default
10Gbps Stacking Ports” on page 141 has the procedure for setting the ID
numbers of the switches in a stack.
Figure 19. Switch ID LED
CLASS
1
LASER PRODUCT
CONSOLE
4567
Switch
ID LED
