The states of the GS980MX/52PSm LEDs are described in Table 13.
Table 13. GS980MX/52PSm Twisted Pair Ports 1-48 LED Functions
LED Ports State Description
L/A
1-40
Solid Green The port has established a 1Gbps link to a network
device.
Flashing
Green
The port is transmitting or receiving data at 1Gbps.
Solid Amber The port has established a 10Mbps or 100Mbps link
to a network device.
Flashing
Amber
The port is transmitting or receiving data at 10Mbps
or 100Mbps.
41-48
Solid Green The port has established a 1/2.5/5Gbps link to a
network device.
Flashing
Green
The port is transmitting or receiving data at
1/2.5/5Gbps.
Solid Amber The port has established a 100Mbps link to a
network device.
Flashing
Amber
The port is transmitting or receiving data at
100Mbps.
Off Possible causes of this state are:
- The port has not established a link with another
network device.
- The LEDs are turned off. To turn on the LEDs, use
the eco-friendly button.
