GS980MX Series Installation Guide for Virtual Chassis Stacking
229
Verifying the Stack
To verify the stack, perform the following procedure:
1. Start a local management session on any switch in the stack. Refer to
“Starting a Local Management Session” on page 150.
2. From the User Exec mode, enter the SHOW STACK command:
awplus> show stack
An example of the command for a stack of four switches is shown in
Figure 90.
Figure 90. SHOW STACK Command
Review the following items:
The command should list all the switches. If the list is incomplete,
refer to Chapter 11, “Troubleshooting” on page 239.
The Operational Status field should be “Normal operations” to
indicate that all the stacking ports are operating normally.
If the Operational Status field is displaying “Not all stack ports are
up,” one or more stacking ports are not being used or cannot
establish links with their counterparts. For more information, refer
to Appendix A, “Technical Specifications” on page 243.
3. Go to Chapter 10, “Cabling the Networking Ports” on page 231, to
complete the installation.
awplus> show stack
Virtual Chassis Stacking summary information
ID Pending ID MAC address Priority Status Role
1 - e01a:ea20:8011 1 Ready Active Master
2 - e01a:ea20:8023 2 Ready Backup Member
3 - e01a:ea20:9a45 3 Ready Backup Member
4 - e01a:ea20:1b8a 4 Ready Backup Member
Operational Status Normal operations
Stack MAC address e01a:ea20:8011
