The back panels are shown in Figure 7 through Figure 10.
Figure 7. GS980MX/10HSm Back Panel
Figure 8. GS980MX/18HSm and GS980MX/52 Back Panel
Figure 9. GS980MX/28 and GS980MX/52 Back Panel
Figure 10. GS980MX/28PSm and GS980MX/52PSm Back Panel
100-240V~
AC Power
Supply
Connector
100-240V~
AC Power
Supply
Connector
100-240VAC~
4587
AC Power
Supply
Connector
100-240 VAC~
AC Power
Supply
Connector
