Chapter 6: Installing the Switch on a Wall
136
Installing the Switch on a Concrete Wall
This section contains the instructions for installing the switch on a
concrete wall. Please review the information in the following sections
before performing the procedure:
“Switch Orientations on a Wall” on page 124
“Installation Guidelines” on page 126
Warning
The device is heavy. Always ask for assistance before moving or
lifting it to avoid injuring yourself or damaging the equipment.
Warning
The device should be installed on the wall by a qualified building
contractor. Serious injury to yourself or others or damage to the
equipment can result if it is not properly fastened to the wall. E105
Note
If the plastic feet have been installed, you must remove them to
install the switch on a concrete wall.
To install the switch on a concrete wall, perform the following procedure:
1. Place the switch on a table.
2. For the GS980MX/28 or GS980MX/28PSm switch, install two wall/
equipment rack brackets to the sides of the unit with the eight
M4x6mm screws included with the switch. Refer to Figure 72 on page
132. For the GS980MX/10HSm, GS980MX/18HSm, GS980MX/52 or
GS980MX/52PSm switch, install four wall/equipment rack brackets to
the sides of the unit with the 16 M4x6mm screws included with the
switch. Refer to Figure 73 on page 133.
3. After attaching the brackets, have another person hold the switch on
the concrete wall at the selected location for the device while you use
a pencil or pen to mark the wall with the locations of the four screw
holes in the four brackets (one screw per bracket). Refer to Figure 76
on page 137.
