Appendix 4 MODBUS Communication
211
Address Name BIT Content
0025H AI1 analog input(V)
0026H AI2 analog input(V)
0027H Output current (A)
0028H Output voltage (V)
0029H Reference frequency (Hz)
002AH (Reserved)
002BH
Terminal
status
0 Terminal X1 1:CLOSED 0:OPEN
1 Terminal X2 1:CLOSED 0:OPEN
2 Terminal X3 1:CLOSED 0:OPEN
3 Terminal X4 1:CLOSED 0:OPEN
4 Terminal X5 1:CLOSED 0:OPEN
5
Terminal X6 ( Only
35R5GB/37R5PB ~
3500G)
1:CLOSED 0:OPEN
6
Terminal X7 ( Only
35R5GB/37R5PB ~
3500G)
1:CLOSED 0:OPEN
7
Terminal X8 ( Only
35R5GB/37R5PB ~
3500G)
1:CLOSED 0:OPEN
8 Terminal DO 1:CLOSED 0:OPEN
9
Terminal Y1 ( Only
35R5GB/37R5PB ~
3500G)
1:CLOSED 0:OPEN
A
Terminal Y2 ( Only
35R5GB/37R5PB ~
3500G)
1:CLOSED 0:OPEN
B RELAY 1 1:CLOSED 0:OPEN
C
RELAY 2 ( Only
35R5GB/37R5PB ~
3500G)
1:CLOSED 0:OPEN
D-F (Reserved)
002CH (Reserved)
To Next Page
