Amazone Condor 12001-C User Manual

Coupling and uncoupling the implement
100
Condor 12001-C/15001-C BAH0030-4 07.15
Marking
Function
Tractor control unit
yellow
Rear frame
Star wheel
Move into working position
Double
acting
Move into transport position
green Boom
Move into working position
Double
acting
/
Move into transport position
blue
coulter
pressure
Increase
Double
acting
Reduce
red
Blower fan
hydraulic
motor
Switch on
Single-
or
double-
acting
1)
Return flow: unpressurised line
2)
1)
Pressure line with priority
2)
Pressureless hose (see section "Installation regulations for the hydraulic fan drive connection", Seite 93).
Check the route of the supply lines.
The supply lines
 Must easily give way to all movements in bends without tensioning,
kinking or rubbing.
 must not chafe against other parts.
