Amazone Condor 12001-C User Manual

Cleaning, maintenance and repairs
Condor 12001-C/15001-C BAH0030-4 07.15
177
12.5.3.5 Installation and removal of hydraulic hose lines
When installing and removing hydraulic hose lines, always observe
the following information:
 Only use original AMAZONE hydraulic hose lines!
 Ensure cleanliness.
 You must always install the hydraulic hose lines so that, in
all states of operation:
 There is no tension, apart from the hose's own weight.
 There is no possibility of compression for short lengths.
 Outer mechanical influences on the hydraulic hose lines are
avoided.
Use appropriate arrangements and fixing to prevent any
scouring of the hoses on components or on each other. If
necessary, secure hydraulic hose lines using protective
covers. Cover sharp-edged components
 The approved bending radii may not be exceeded.
 When connecting a hydraulic hose line to moving parts, the
hose length must be appropriate so that the smallest
approved bending radius is not undershot over the whole
area of movement and/or the hydraulic hose line is not over-
tensioned.
 Fix the hydraulic hose lines to the intended fixing points.
There, avoid hose clips, which impair the natural movement
and length changes of the hose.
 It is forbidden to paint over hydraulic hose lines!
