Amazone Condor 12001-C User Manual

Layout and function
Condor 12001-C/15001-C BAH0030-4 07.15
51
5.1.2 Uncoupling the hydraulic hose lines
1. Swivel the actuation lever on the control
valve on the tractor to float position (neutral
position).
2. Release the hydraulic connectors from the
hydraulic sockets.
3. Protect the hydraulic connectors and
hydraulic connector sockets from soiling
using the dust protection caps.
Fig. 30
4. Place the hydraulic hose lines in the hose
cabinet.
Fig. 31
