Layout and function
58
Condor 12001-C/15001-C BAH0030-4 07.15
5.2.3 Hydraulic operating brake system
To control the hydraulic service brake system, the tractor requires a
hydraulic braking device.
5.2.3.1 Coupling the hydraulic service brake system
Only couple clean hydraulic connectors.
1. Remove the protective cap (Fig. 42/1).
2. If necessary, clean the hydraulic connector
(Fig. 41) and hydraulic socket.
3. Couple the implement's hydraulic socket
with the tractor's hydraulic connector.
Fig. 41
5.2.3.2 Uncoupling the hydraulic service brake system
1. Release the hydraulic connectors from the
hydraulic sockets.
2. Secure the hydraulic socket and hydraulic
connector with protective caps (Fig. 42/1)
against soiling.
3. Place the hydraulic hose line on the holder
for the supply lines.
Fig. 42
