Which metering volume [D
V
] is required?
1. Determination of the smallest metering
volume:
1.1 Gearbox position 80 : [i
80
] = 0.351 1/m
1.2 D
V80
= 352 cm³
3
80
1,0
351,0
cm
G
AAB
D
L
MD
V

33
80
3521,0
85,0
175
351,0
6
cmcmD
V

2. Determination of the largest metering
volume:
2.1 Gearbox position 20 : [i
20
] = 0.088 1/m
2.2 D
V20
= 1404 cm³
3
20
1,0
088,0
cm
G
AAB
D
L
MD
V

33
20
14041,0
85,0
175
088,0
6
cmcmD
V

3. The metering volume [D
V
] must be between
352 cm³ and 1404 cm³.
4. The metering roller is selected based on the
Metering Rollers Table (see Seite 69).
8.3 Installing/removing the metering roller
The metering roller can be replaced more easily if the hopper is
empty.
1. Disengage the tractor PTO shaft, engage
the tractor parking brake, shut off the tractor
engine and remove the ignition key.
2. Close the opening to the hopper (only
necessary when the hopper is full).
2.1 Remove the key (Fig. 117/1) from the
holder.
2.2 Release two nuts (Fig. 118/1) but do
not remove.
Fig. 117
Fig. 118
