Layout and function
56
Condor 12001-C/15001-C BAH0030-4 07.15
5.2.2.2 Uncoupling the supply and brake line
WARNING
Risk of crushing, cutting, being caught or drawn in, or impact
through the accidentally rolling implement, if the service brake is
released.
Always first disconnect the hose coupling of the supply line (red),
followed by the hose coupling of the brake line (yellow).
When the supply line (red) is uncoupled from the tractor, the service
brake of the implement moves into braking position.
Always keep to this order, as otherwise the operating brake system
will trip and may set the unbraked implement moving.
DANGER
First secure the implement with the
wheel chocks (Fig. 37) before you
uncouple the implement from the
tractor!
Fig. 37
Fig. 38/…
(1) Wheel chocks
(parking position under the seed hopper)
Fig. 38
