Layout and function
82
Condor 12001-C/15001-C BAH0030-4 07.15
5.16.2 Tramline rhythm no. 2
Working width of the seed drill (A) 12 m
Working width of the fertiliser spreader/field
sprayer (B)
48 m
Tramline distance 48 m
Tramline counter display (D) 2/0/0/1
Fig. 89
5.16.3 Tramline rhythm no. 3
Working width of the seed drill (A) 12 m
Fig. 90
Working width of the fertiliser spreader/field
sprayer (B)
36 m
Tramline distance 36 m
Tramline counter display (D) 2/0/1
Working width of the seed drill (A) 15 m
Working width of the fertiliser spreader/field
sprayer (B)
45 m
Tramline distance 45 m
Tramline counter display (D) 2/0/1
