Layout and function
Condor 12001-C/15001-C BAH0030-4 07.15
61
5.6 Hopper
The large hopper (Fig. 46/1) has three chambers
for carrying seed and fertiliser.
The hopper (Fig. 46/1) is easily accessible for
filling, calibration, and residual emptying.
The full-area opening of the hopper allows rapid
filling.
Fig. 46
When the blower fan is switched on, an even
pressure is built up in the hopper and the
delivery system.
When the blower fan is running, the hopper
cover (Fig. 47/1) must be firmly closed (see
section "Filling the hopper", Seite 144).
Fig. 47
A pressure gauge (Fig. 48/1) indicates the
pressure in the sealed delivery system.
Fig. 48
