Cleaning, maintenance and repairs
188
Condor 12001-C/15001-C BAH0030-4 07.15
12.6 Screw tightening torques
M S
8.8 10.9 12.9
M 8
13
25 35 41
M 8x1 27 38 41
M 10
16 (17)
49 69 83
M 10x1 52 73 88
M 12
18 (19)
86 120 145
M 12x1.5 90 125 150
M 14
22
135 190 230
M 14x1.5 150 210 250
M 16
24
210 300 355
M 16x1.5 225 315 380
M 18
27
290 405 485
M 18x1.5 325 460 550
M 20
30
410 580 690
M 20x1.5 460 640 770
M 22
32
550 780 930
M 22x1.5 610 860 1050
M 24
36
710 1000 1200
M 24x2 780 1100 1300
M 27
41
1050 1500 1800
M 27x2 1150 1600 1950
M 30
46
1450 2000 2400
M 30x2 1600 2250 2700
M M4 M5 M6 M8 M10 M12 M14 M16 M18 M20 M22 M24
2.3 4.6 7.9 19.3 39 66 106 162 232 326 247 314
Tightening torques of the wheel and hub screws
[see Table (Fig. 214), Seite 169].
