Product description
Condor 12001-C/15001-C BAH0030-4 07.15
47
4.8 Technical data
Condor 12001-C 15001-C
Working width [m] 12.0 15.0
Row spacing of the coulter [cm] 25 / 33.3 25 / 31.3
Number of sowing units 48 / 36 60 / 48
Hopper content [l]
8000 / - / -
2660 / 2320 / 3060
8000 / - / -
2660 / 2320 / 3060
Payload (on the field) [kg] 8000 8000
Working speed [km/h] 8 - 10 8 – 10
Power requirement (from)
[kW/bh
p]
150 / 204 180 / 245
Category of the coupling points
Cat. 3
Cat. 4N (optional)
Cat. 5 (optional)
Cat. 3
Cat. 4N (optional)
Cat. 5 (optional)
Tyres 700/55-26.5 700/55-26.5
Overall length (in working position) [mm] 10000 11500
Total height (in working position) [mm] 3300 3300
Maximum drawbar load
with full hopper
(on the field)
[kg] 7000 7000
Service brake system (optional)
1)
(connection on tractor)
Dual-circuit pneumatic braking system
or
hydraulic braking system
2)
1)
The implement may not be equipped with a brake system.
Operation without a brake system is not permitted in Germany and in some other countries.
2)
Operation with a hydraulic brake system is not permitted in Germany and in several other countries.
Road transport only with empty hopper!
Road transport data
Large area seed drill Condor 12001-C Condor 15001-C
Total width (in transport position) [m] 3.0 3.0
Total length (in transport position) [m] 9.0 10.5
Total height (in transport position) [m] 4.0 4.0
Empty weight (basic weight) [kg] 9500 10500
Permissible total weight [kg] 10500 11000
Maximum load for road travel [kg] 500 500
Permissible rear axle load [kg] 7000 7500
Perm. drawbar load (F
H
)
when driving on the road
(see rating plate)
[kg] 4000 4500
Permissible max.
speed
without
brake system
1)
[km/h] 10 10
with dual-circuit
pneumatic braking
system
[km/h] 40 40
with hydraulic
brake system
[km/h] 25 25
1)
Operation without a brake system is not permitted in Germany and in several other countries.
