Amazone Condor 12001-C User Manual

Layout and function
74
Condor 12001-C/15001-C BAH0030-4 07.15
5.12 Distributor head
In the distributor head (Fig. 72/1), the seed-
fertiliser mix is distributed uniformly over all the
seed coulters.
Fig. 72
5.12.1 Seed tube monitoring (optional)
The seed tube hoses represent the connection
between the distributor head and the coulters.
Each seed tube hose can be equipped with a
sensor (Fig. 73/1) that detects the seed flow.
If the seed flow is stopped in one of the seed
tube hoses equipped with a sensor, a warning
message is issued.
Fig. 73
If there is blockage at one of the coulters, the air escapes with the
seed through the air separator. The seed line monitoring is not
triggered. There is no warning message.
The warning message is only triggered if the if the seed line is
blocked between the sensor and the air separator.
