Amazone Condor 12001-C User Manual

Settings
Condor 12001-C/15001-C BAH0030-4 07.15
127
8.8 Setting the coulter pressure
WARNING
Direct people out of the danger area.
Fig. 152/…
(1) With the coulter pressure, the depth of the
seed bed is adjusted.
Fig. 152
1. Put the coulter pressure to the desired
position
1.1 Put in float position
Fig. 153
The pressure gauge (Fig. 153/1) is
unpressurised:
 The coulters work with normal coulter
pressure.
1.2 Apply pressure to the hydraulic
cylinder by actuating the blue control
unit
Fig. 154
The pressure gauge (Fig. 153/1) is
pressurised, the indicator (Fig. 153/3)
changes its position:
 The coulters work with increased coulter
pressure.
