Layout and function
Condor 12001-C/15001-C BAH0030-4 07.15
67
For calibration and emptying, the seed/fertiliser is
collected in a trough (Fig. 61/1) under the
metering unit.
The delivery tube has an opening at the bottom.
Two tensioning hooks (Fig. 61/2) close the
opening with a rubber mat (Fig. 61/3).
Fig. 61
5.10.1 Metering rollers
The seed metering unit is equipped with an exchangeable metering
roller. The metering roller selection is dependent on
 the seed type
 the spread rate.
Fit all of the seed metering units with the same metering roller.
Fit the fertiliser metering unit with the fertiliser metering roller.
7.5 cm
3
20 cm
3
