Amazone Condor 12001-C User Manual

Settings
Condor 12001-C/15001-C BAH0030-4 07.15
111
3. Loosen both screws (Fig. 120/1).
4. Twist and remove the bearing cover (Fig.
121).
Fig. 119
5. Loosen the two bolts
5.1 Remove the key (Fig. 117/1) from the
holder.
5.2 Loosen the nuts (Fig. 120/1) but do not
remove.
Fig. 120
6. Remove the bearing cover (Fig. 121/1)
6.1 Turn the bearing cover (Fig. 121/2)
6.2 Pull off the bearing cover (Fig. 121/2).
Fig. 121
7. Pull the metering roller out of the metering
unit.
Fig. 122
Install the metering roller in the
reverse sequence.
