Settings
124
Condor 12001-C/15001-C BAH0030-4 07.15
Setting the boom pressure
The boom pressure setting depends on the
Soil texture
Coulter pressure
Forward speed
1. Start the blower and allow to rotate with
3500 rpm.
2. Undo the lock nut of the pressure relief
valve (Fig. 145/1) and unscrew the
adjustment screw.
The pressure gauge for loading the boom
(Fig. 146/1) is now at 0 bar.
3. Screw in the adjustment screw of the
pressure relief valve (Fig. 145/2) until the
pressure gauge displays 40 bar.
3.1 The side booms move up on the
outside:
Increase the pressure on the side
boom by 5 bar.
3.2 Support wheels of the boom are
exposed to high loads:
Reduce the pressure on the side boom
by 5 bar.
4. Tighten the lock nut.
