Use of the implement
Condor 12001-C/15001-C BAH0030-4 07.15
145
When not in use, the ladder (Fig.
172) must be swivelled in a slanted
position.
In operating position, the ladder can
be damaged by the drawbar when
turning the implement.
Fig. 172
6. Move the ladder into operating position.
6.1 Press the (Fig. 173/1) button.
6.2 Press the lever (Fig. 173/2) down.
Fig. 173
6.3 Take hold of the ladder by the handle
(Fig. 174/2) and swivel into operating
position.
Make sure that the ladder engages.
Fig. 174
7. Climb on the loading plate via the ladder.
Fig. 175
