Product description
Condor 12001-C/15001-C BAH0030-4 07.15
41
Fig. 15/...
(1) Tarpaulin cover
(2) Locking lever
Fig. 15
Fig. 16/...
(1) Level sensor
Fig. 16
Fig. 17/…
(1) Seed tube monitoring (optional)
The seed tube hoses represent the
connection between the distributor head
and the coulters.
Each seed tube hose can be equipped with
a sensor (Fig. 17/1) that detects the seed
flow.
Fig. 17
