Amazone Precea 3000 - Using the Loading Board

1. To  the shifted tramline,
see "ISOBUS software operating manual" >
"Configuring the tramline control".
2. After  the shifted tramline,
check whether the desired coulters are shifted.
The large spacer elements
1
are 38 mm wide. The
small spacer elements
2
are 25.4 mm wide.
3. To adjust the tramline width for the cultivating
implement,
add the desired spacer elements
or
remove the desired spacer elements.
CMS-I-00005546
6.4.21 Using the loading board
1. Remove the safety cotter pin
1
.
CMS-I-00002744
2. Pull out the ladder
1
and swivel it down.
CMS-I-00002836
CMS-T-00003737-B.1
6 | Preparing the machine
Preparing the implement for operation
MG6660-EN-II | D.1 | 27.09.2021
143
