3. Climb onto the loading board
2
using the ladder.
4. After use, swivel the ladder
1
up and put it in
the parking position.
5. Secure the ladder in the parking position with the
cotter pin.
CMS-I-00002745
6.4.22 Adjusting the filling auger
REQUIREMENTS
The implement is not coupled to the tractor
The implement is properly parked
CAUTION
Risk of tripping due to difficult access to
the filling auger
For safe access to the  auger,
use a platform ladder.
1. Fertiliser hopper is  unevenly in the
direction of travel.
Loosen the bolt
2
.
2. Loosen the bolt
1
and remove it.
3. Move the outlet to the desired position.
4. Insert the bolt
1
and tighten it.
5. Tighten the bolt
2
.
CMS-I-00002029
CMS-T-00002217-C.1
6 | Preparing the machine
Preparing the implement for operation
MG6660-EN-II | D.1 | 27.09.2021
144
