6. Close the cover
against the spring pressure.
7. To lock the cover,
Continue actuating the lever
.
The cover will be locked on the chain tensioner
.
CMS-I-00002647
9.3.3 Lubricating the roller chain in the trailing wheel drive
INTERVAL
After the first 10 operating hours
Every 50 operating hours
or
at the end of the season
1. Remove the bolts
.
2. Remove the cover
.
CMS-I-00002721
CMS-T-00005450-B.1
9 | Repairing the machine
Lubricating the roller chains
MG6660-EN-II | D.1 | 27.09.2021
221
