Amazone Precea 3000 User Manual

REQUIREMENTS
The tractor and implement are secured
1. Remove the dust caps
1
.
2. Unscrew and remove the central bolts
2
.
NOTE
The central bolts have different threads:
The right central bolt has right-hand thread
The left central bolt has left-hand thread
3. Remove the cutting discs
3
.
4. Pay attention to the number of spacer discs
4
.
5. Replace inner scrapers
5
if worn.
6. Install the cutting discs.
7. Put on and tighten the central bolt.
8. Install the dust caps.
1 2
3
4
5
220 Nm
CMS-I-00002020
9.1.10 Checking the wheel bolt tightening torque
INTERVAL
After initial operation
Every 50 operating hours
Tyres
Wheel bolt tightening
torque
Tyres 6.5/80x15-AS 325 Nm
Tyres 26x12-12 AS 325 Nm
Check the wheel bolt tightening torque.
CMS-T-00002382-C.1
9 | Repairing the machine
Maintaining the machine
MG6660-EN-II | D.1 | 27.09.2021
191
