9. Put on and tighten the bolts on the bearing seat.
10. Install new cutting discs.
11. To ensure that the cutting discs touch slightly,
adjust the spacing of the cutting discs with the
spacer discs
.
12. Install spacer discs that are not required on the
opposite side of the cutting disc bearing with the
central bolt.
13. Put on and tighten the central bolt.
14. Install the dust caps.
15. Install the depth control wheel along with the
bracket.
16. Put on and tighten the bolt.
9.1.3 Adjusting the cutting disc distance on the PreTeC coulter
INTERVAL
Every 100 operating hours
or
as required
1. Remove the depth control wheel along with the
bracket
.
2. Remove the dust caps
.
3. Unscrew and remove the central bolts
.
NOTE
The central bolts have different threads:
The right central bolt has right-hand thread
The left central bolt has left-hand thread
CMS-I-00002017
CMS-T-00002376-D.1
