Amazone Precea 3000 - Checking the Tyre Inflation Pressure; Checking the V-Ribbed Belt

9.1.15 Checking the tyre inflation pressure
INTERVAL
After initial operation
Every 50 operating hours
Tyres Tyre inflation pressure
Tyres 6.5/80x15-AS 2.4 bar
Tyres 26x12-12 AS 2.4 bar
Check the tyre inflation pressure.
9.1.16
Checking the V-ribbed belt
INTERVAL
Every 200 operating hours
or
Every 12 months
1. Remove the bolt
1
and nut
2
.
2. Slide the bush
3
onto the connecting shaft.
3. Disconnect the connection on both sides.
4. Remove the connecting shaft.
1
2
3
4
CMS-I-00002012
5. Remove the fastening bolt
1
.
6. Unscrew the fastening bolt
2
.
7. Remove the upper protective cover
3
.
8. Check the V-ribbed belt.
If damage, fraying, transverse cracks or broken
ribs are visible, replace the V-ribbed belt.
CMS-I-00002014
CMS-T-00002387-A.1
CMS-T-00002388-D.1
