ACQUIRING DATA
iKon-L SECTION 5
Page 68
Multi-Track mode allows you to create one or more tracks. You can define (in rows) the height of each track
and the offset, which in effect ‘raises’ or ‘lowers’ on the CCD-chip the pattern of tracks from which you will
readout charge. In this way you can adjust the position of the tracks to match a light pattern produced on the
CCD-chip by a fiber bundle, for example.
To define multiple tracks on the CCD-chip, select Multi-track from the Readout Modes drop-down menu in the
Setup Acquisition dialog box. The Multi-track dialog box appears e.g.:
Click the MT Setup.. tab and the Multi-track dialog box opens, e.g.:
Type in the required parameters then click OK.
