ACQUIRING DATA
iKon-L SECTION 5
Page 83
5.17 - FILE INFORMATION
Details of the Acquisition selection can be viewed by clicking the button on the Main Window which opens
the Information dialog box (you can enter your own notes in the Comments box):
The table below details the type of information contained in the dialog box.
Filename
The filename associated with the active Data Window
( If the data has not yet been saved this will default to Acquisition)
Date and time
The date & time at which the acquisition was made.
Software Version
The version of Solis software in use
Unstabilised Temperature (C)
The temperature to which the detector had been cooled.
Model
The model number of the camera/detector
Data Type
Data Type, i.e. Counts, % Transmittance, etc.
Acquisition Mode
Single Scan, Accumulate, Kinetics or Fast Kinetics
Trigger Mode
Internal, External, Fast External or External Start
Exposure Time (secs)
‘Fire’ pulse length
Readout Mode
Full Resolution Image, Multi-Track or Full Vertical Binning
Horizontal Binning
Minimum = 1, Maximum = Sensor Width
Vertical Binning
Minimum = 1, Maximum = Sensor Height
Horizontally flipped
True or False
Vertically flipped
True or False
Clockwise rotation
True or False
Anti-clockwise rotation
True or False
Baseline Clamp
OFF or ON
Vertical Shift Speed (usecs)
Value in microseconds - System dependant
Pre-amplifier Gain
1,2 or 4
Serial Number
Serial number of the camera being used
Pixel Readout Rate
As set for the Horizontal Readout Rate
