PRE-ACQUISITION
iKon-L SECTION 4
Page 43
The Andor Solis software allows you to spool acquisition data direct to the hard disk of your PC. This is
particularly useful when acquiring a series of many images. The amount of data generated by a Kinetic Series
of, for example 1000 acquisitions, is huge and more than most PC RAM can handle.
To select click on the Spooling tab and the Spooling dialog box appears e.g.:
With the spooling function enabled, data is written directly to the hard disk of you PC, as it is being acquired. To
enable the spooling function on your software, tick the Enable Spooling box. You must also enter a stem
name, and also select a location for the for this spooled data file, e.g.:
NOTE: Spooling large amounts of data straight to hard disk for later retrieval requires a hard disk of
sufficient read-write speed. Andor recommends only very high-speed hard disk drives be used for this
type of operation.
