TABLE OF CONTENTS
iKon-L TABLE OF CONTENTS
Page 8
PAGE
SECTION 6 - DISPLAYING DATA 84
6.1 - DISPLAY MODES 84
6.2 - DISPLAY PREFERENCES 85
6.3 - AXIS DEFINITIONS 86
6.4 - AXIS SETUP 87
6.5 - ZOOM BOX 88
6.6 - ZOOMING & SCROLLING 89
6.6.1 - Zoom In & Zoom Out 89
6.6.2 - Scrolling 89
6.6.3 - Reset 89
6.7 - 2D DISPLAY MODE 90
6.7.1 - 2D display mode preferences 91
6.7.2 - Peak Search 92
6.7.2.1 - Peak Search Sensitivity 92
6.7.3 - Peak Labeling 92
6.7.3.1 - Labels on Peaks or Troughs 92
6.7.3.2 - Maximum Number of Labeled Peaks 92
6.7.3.3 - Format Labels 92
6.7.3.4 - Weighted Peak 92
6.7.3.5 - Pixel Peak 92
6.7.3.6 - Label Peaks in all Overlaid Spectra 92
6.7.4 - 2D with Peak Labeling 93
6.7.5 - Overlay 94
6.7.5.1 - Overlay and Keep 97
6.7.5.2 - Scale to Active 98
6.7.5.3 - Remove Overlay 98
6.7.6 - 2D with Chemical Labels 99
6.7.7 - Baseline Correction 100
6.8 - 3D DISPLAY MODE 101
6.8.1 - 3D display mode preferences 102
