3-7 VNA Key Functions - File Menu Chapter 3 — Vector Network Analyzer
3-30 MS20xxA VNA Master UG 10580-00166 Rev. C
Save Measurement
Initiates a dialog box to name and save the active trace. The saved measurement
trace can be named using the keypad to select numbers, the rotary knob to
highlight a number or character and pressing the knob to select, or by selecting
the soft key for each letter. Use the
Shift key to select an upper case letter. Use
the
Left/Right directional arrows to move the cursor position. Press Enter to save
the measurement trace. Measurements are saved in a directory called /usr on the
Compact Flash memory module and the USB Flash Drive.
Save Limit Line
Not available in VNA Mode.
Save On Event…
Not available in VNA mode.
Save Screen as JPEG
This function saves a measurement trace as a graphics file. The saved
measurement can be named using the keypad to select numbers, the rotary knob
to highlight a number or character and pressing the knob to select, or by selecting
the soft key for each letter. Use the
Shift key to select an upper case letter. Use
the
Left/Right directional arrows to move the cursor position. Press Enter to save
the measurement after entering the file name. The file is saved in the internal
memory with the specified name, with .jpg appended.
Directory Management
Brings up the Directory Management soft menu. For a description of the
directory management menu and soft keys, see “ Directory Management” on
page 3-32.
Back
The Back key returns to the previous menu.
Recall
Brings up the Recall setup menu.
Recall Setup
This soft key brings up a selection box that allows selection and recall of a
previously stored instrument setup in the current storage location. Use the
rotary knob or the
Up/Down arrow keys to highlight the saved setup, and press
Enter, the rotary knob, or the Recall soft key to select. All current instrument
settings are replaced by the stored setup information. Press the
Esc key to cancel
the recall.
Note
If a measurement has been previously saved, the Save Measurement dialog box
will open with the previously saved name displayed.
To save the new measurement with a similar name (for example, Trace-1, Trace-2,
etc.) simply press the Right directional arrow and add the changes.
To create a completely new name, use the keypad, the rotary knob or select the
soft key for each letter.
