Multipath Menu
Key Sequence: Measurements > OTA > Multipath
EMF Menu
Key Sequence: Measurements > OTA > EMF
Refer to “W-CDMA EMF Menu” on page 8-10.
Scrambling Code: Set the scrambling codes to manual or auto.
Manual Scrambling Code: Sets the manual scrambling code.
Vert Display: Switch vertical display between RSCP and Rel Pwr.
Horiz Display: Switch between Chips and uSec for the horizontal display.
Distance: Switch between meters and feet.
Back: Returns to the “Over-The-Air Menu” on page 3-38.
Figure 3-31. W-CDMA/HSPA+ Multipath Menu
