EFD1000 PFD Pilot’s Guide
CHAPTER 5, CUSTOMIZING THE EFD1000 PFD
EFD1000 PFD Pilot’s Guide
EFD1000 PFD Pilot’s Guide Page 5-9A-01-184-00 REV B
V-SPEED DEFINITION PRE-SET
BANDS
ADJUSTABLE
TEXT LABELS
PRE-SET
MARKERS
Vlo
Retract maximum landing
gear operation speed
x
Vmc
(Multi-engine planes)
Single engine minimum
control
x
x (Red Line)
Vyse
(Multi-engine planes)
Single engine minimum
control
x
(Multi-engine
planes) Single
engine best rate
of climb
Initial ap extension
x
Table 5-9 EFD1000 PFD V-speed Denitions
NOTE
Setting the value of the white triangle,
Vyse, and Vmc markers to zero (0)
during installation, disables the
markers. Setting any of the adjustable
V-speed values to zero (0) disables the
applicable label.
