4.2.16 Frame Communication Setting
An arbitration error can be generated for a part with checked below the waveform.
The display method is as follows.
Mouse operation
Right-click → left-click ANALYZE → left-click Frame Communication Setting
Unit operation
Press the ANALYZE key.
→ press L CLICK over Frame
Communication Setting
Press R CLICK → press L CLICK over ANALYZE
