5.2.13 Generate HDCP Status
Displays the constants used in HDCP authentication on the HDMI sender side.
The display method is as follows.
Right-click → left-click GENERATE → left-click HDCP Status
→ press L CLICK over HDCP
Status
Press R CLICK → press L CLICK over GENERATE
The HDCP display items when GUI display are as follows.
Pseudo-random value used in HDCP authentication that the VA-1842 sent
to the receiver or repeater device
Key Selection Vector of the VA-1842
Key Selection Vector of the receiver or repeater device
Authentication value calculated by the receiver or repeater device
HDMI mode, repeater support, etc.
Total number of devices connected to downstream *
Total number of stages connected to downstream *
Value for judging whether or not the KSV list generated by the repeater
device is appropriate *
KSV values of the devices connected to downstream that have been
collected by the VA-1842 *
Receiver ID of the receiver or repeater device read with certrx of
AKE_Send_Cert
Version information sent with AKE_Init
Pseudo-random value sent with AKE_Init
Version information and repeater status read with AKE_Send_Cert
Pseudo-random value read with AKE_Send_Cert
Master key information sent with No_Stored_km
Master key information sent with Stored_km
