6.3.32 CECT 11.2.10 OSD Display

When “ALL TEST” is selected, the tests for the test IDs are started. When a test ID number is clicked with the

mouse, only the selected test is started. The procedures for the tests performed with the VA-1842 are shown

below.

Item

Test procedure

Pass criteria

OSD Display

Connect the HDMI output of the DUT and the input of the TE. Then perform the tests.

11.2.10-1

Change to a mode that can use the OSD function of

a TV, and change the current OSD display.

DUT sends <Set OSD String> with the

correct parameter.
