4.1.15 HDCP Status
Displays each constant used in HDCP authentication on the HDMI receiver side.
The display method is as follows.
Right-click → left-click ANALYZE → left-click HDCP Status
→ press L CLICK over HDCP Status
Press R CLICK → press L CLICK over ANALYZE
The HDCP display items when GUI display are as follows.
Pseudo-random value used for HDCP authentication that is sent from the
transmitter to the VA-1842
Key Selection Vector of the sender side
Key Selection Vector of the VA-1842
Authentication value calculated by VA-1842
HDMI mode, repeater support, etc.
Total number of devices connected to downstream *
Total number of stages connected to downstream *
KSV values of the devices connected to downstream that have been
collected by the VA-1842 *
Value for judging whether or not the KSV list generated by the VA-1842 is
appropriate *
Receiver ID of the VA-1842 read with certrx of AKE_Send_Cert
Version information sent with AKE_Init
Pseudo-random value sent with AKE_Init
Version information and repeater status read with AKE_Send_Cert
Pseudo-random value read with AKE_Send_Cert
Master key information sent with No_Stored_km
Master key information sent with Stored_km
Pseudo-random nonce sent with LC_Init
Section key information sent with SKE_Send_Eks
Pseudo-random number sent with SKE_Send_Eks
