ASTRO VA-1842 - CECT 11.2.8 Tuner Control

Chapter 6 Compliance Test
217
6.3.30 CECT 11.2.8 Tuner Control
When “ALL TEST” is selected, the tests for the test IDs are started. When a test ID number is clicked with the
mouse, only the selected test is started. The procedures for the tests performed with the VA-1842 are shown
below.
Item
Test procedure
Pass criteria
Tuner Control
Connect the HDMI output of the DUT and the input of the TE. Then perform the tests.
11.2.8-1
Change the logical address to 0, 1, 3, 4, and 5, and
perform the following procedure.
Check that the DUT is powered on and that Digital
Service 1 in CDF is selected.
Send <Select Digital Service> [Digital Service2].
Changed to Service 2.
11.2.8-2
Check that the DUT is powered on and that Digital
Service 1 in CDF is selected.
Send <Select Digital Service> [Digital Service2] from
logical address 15.
Ignores the message.
11.2.8-3
Check that the DUT is powered on and that Digital
Service 1 in CDF is selected.
Send <Select Digital Service> [Digital Service1].
Ignores the message.
11.2.8-4
Change the logical address to 0, 1, 3, 4, and 5, and
perform the following procedure.
Check that the DUT is powered on and that
Analogue Service 1 in CDF is selected.
Send <Select Analogue Service> [Analogue
Service2].
Changed to Service 2.
