Chapter 6 Compliance Test
239
6.4.4 HDCP1.4 CTS 2C
When a test ID number is clicked with the mouse, the selected test is started. While testing is in progress, the
settings required for the tests are set automatically. The following shows the test list.
Test list
TEST ID
Name
Description
2C-01
Regular procedure: With HDMI-capable
Transmitter
Performs a check of the HDCP protocol for when a
sink device is connected to the DUT.
2C-02
Irregular procedure: (First part of
authentication) New Authentication.
Performs a check of the HDCP protocol for when
initial authentication is started again after the first part
of authentication.
2C-03
Irregular procedure: (Third part of
authentication) New Authentication
Performs a check of the HDCP protocol for when
initial authentication is started again after the third
part of authentication.
2C-04
Regular procedure: With DVI Transmitter
Performs a check of the HDCP protocol for when
authentication with DVI signals is performed. * The
position of the ENC_EN signal is not changed.
