Chapter 6 Compliance Test

221

6.3.33 CECT 11.2.11 Device OSD Name Transfer

When “ALL TEST” is selected, the tests for the test IDs are started. When a test ID number is clicked with the

mouse, only the selected test is started. The procedures for the tests performed with the VA-1842 are shown

below.

Item

Test procedure

Pass criteria

Device OSD Name Transfer

Connect the HDMI output of the DUT and the input of the TE. Then perform the tests.

11.2.11-1

Change the logical address to 0, 1, 3, 4, and 5, and

send <Give OSD Name>.

DUT sends <Set OSD Name>.

11.2.11-2

Send <Give OSD Name> from logical address 15.

DUT ignores the message.
