ASTRO VA-1842 - CECT 11.2.6 System Information

Chapter 6 Compliance Test
213
6.3.28 CECT 11.2.6 System Information
When “ALL TEST” is selected, the tests for the test IDs are started. When a test ID number is clicked with the
mouse, only the selected test is started. The procedures for the tests performed with the VA-1842 are shown
below.
Item
Test procedure
Pass criteria
System Information
Connect the HDMI output of the DUT and the input of the TE. Then perform the tests.
11.2.6-1
Send <Polling Message>.
Returns Ack.
11.2.6-2
Change the logical address to 0, 1, 3, 4, 5, and 15,
and send <Give Physical Address>.
DUT broadcasts <Report Physical Address>.
11.2.6-3
Broadcast <Set Menu Language> with the
parameter of a language different from the currently
set language.
The DUT language setting is updated.
11.2.6-4
Broadcast <Set Menu Language> with the
parameter of an unsupported language different from
the currently set language.
The DUT language setting is not updated.
11.2.6-5
Change the logical address to 1, 3, 4, 5, and 15 and
broadcast <Set Menu Language> with the parameter
of a language different from the currently set
language.
The DUT language setting is not updated.
11.2.6-6
Send <Get CEC Version>.
Sends <CEC Version>.
11.2.6-7
Send <Get Menu Language> from logical address 0.
Does not send <Set Menu Language>.
